Color
White, Blue, Black and Others
Tensile Strength
30~40 MPa
Transport Package
Wooden Box
Production Capacity
500 Tons Per Year
HDPE (High Density Polyethylene) is a versatile material where higher density improves its tensile strength, surface hardness, and heat deflection temperature. It is widely recognized for its excellent impact resistance, chemical stability, low water absorption, and superior resistance to UV radiation.
✓ Good fatigue and wear resistance
✓ Super low water absorption
✓ Cold resistant
✓ Good surface smoothness
✓ Stress cracking protection
✓ Low steam permeability
✓ Good electrical insulation
✓ Environmental friendly & Recyclable
-
■
Furnitures, doors, windows, and chopping boards
-
■
Water storage boxes and industrial tanks
-
■
Playground barriers and safety structures
| PROPERTIES |
Test Method |
Unit |
Value |
| I. Physical Properties |
| Density |
ISO 1183 |
g/cm3 |
0.95~0.96 |
| Water absorption 24hrs |
ISO 62 |
% |
0.01 |
| II. Thermal Properties |
| Heat deflection temperature - HDT/A |
ISO 75-2 |
ºC |
55 |
| Min. service temperature |
- |
ºC |
-30 |
| Max. service temperature-Long Term |
- |
ºC |
90 |
| Thermal conductivity at 23 ºC |
DIN 11359 |
W/(K*m) |
0.42 |
| Flammability Rating (6mm thickness) |
UL 94 |
- |
HB |
| III. Mechanical Properties at 23ºC |
| Tensile strength at yield |
ISO 527-2 |
MPa |
27 |
| Tensile strength at break |
ISO 527-2 |
Mpa |
35 |
| Elongation at break |
ISO 527-2 |
% |
700 |
| Hardness - Shore D |
DIN 53505 |
- |
64 |
| IV. Electrical Properties at 23ºC |
| Dielectric constant at 1 MHz |
IEC 60250 |
106Hz |
2.3 |
| Volume resistivity |
IEC 60093 |
Ohm (Ω) * cm |
>1016 |
| Dielectric strength |
IEC 60243-1 |
kV/mm |
17 |
NOTE: 1 g/cm3 = 1,000 kg/m3, 1 Mpa = 1 N/mm2, 1kV/mm = 1 MV/m
Frequently Asked Questions
What are the primary benefits of Anti-UV HDPE sheets?
Anti-UV HDPE sheets offer excellent resistance to degradation from sunlight, high impact strength, and very low water absorption, making them ideal for long-term outdoor use.
Can these sheets be used for food contact applications?
Yes, HDPE is commonly used for chopping boards and food processing equipment due to its durability, chemical resistance, and ease of cleaning.
What is the service temperature range for HDPE sheets?
These sheets can typically be used in environments ranging from -30ºC up to a long-term service temperature of 90ºC.
Is the material environmentally friendly?
Yes, HDPE is an environmentally friendly material and is fully recyclable, contributing to sustainable manufacturing processes.
How does HDPE handle chemical exposure?
HDPE provides excellent chemical resistance to most acids, alkalis, and organic solvents, which is why it's frequently used for liquid storage and chemical containers.
What thicknesses are available for these PE sheets?
Our production capabilities allow for a thickness range from 1mm up to 350mm to suit various industrial requirements.
